Housing
No.
Shat dia
d1 (mm)
Dimensions(mm) Housing
Wt (kg)
Bearing
No.
Adapter
Sleeve
Locating Ring
h
h12
W L a b c m g
H12
f1
H12
f2 d2
H12
d3
H12
v u s Number QTY
S3024K 110 112 215 150 390 110 40 320 56 8 10.7 113 135 30 36 M24 16.5 23024K H3024 R180/10 1
S3026K 115 125 239 160 420 120 45 350 62 8 10.7 118 140 30 36 M24 19.3 23026K H3026 R200/10 1
S3028K 125 140 259 170 420 120 45 350 63 9 12.2 128 154 30 36 M24 24.6 23028K H3028 R210/10 1
S3030K 135 150 278 175 460 130 45 380 66 9 12.2 138 164 30 36 M24 29 23030K H3030 R225/10 1
S3032K 140 150 288 190 470 130 50 390 70 10 13.7 143 173 30 36 M24 37 23032K H3032 R240/10 1
S3034K 150 160 320 200 540 160 55 450 77 10 13.7 153 183 36 48 M30 45 23034K H3034 R260/10 1
S3036K 160 170 340 210 560 160 55 470 84 10 13.7 163 193 36 48 M30 65 23036K H3036 R280/10 1
S3038K 170 170 353 210 560 160 55 470 85 10 13.7 173 203 36 48 M30 67 23038K H3038 R290/10 1
S3040K 180 180 373 235 615 170 60 515 92 10 13.7 183 213 36 48 M30 72 23040K H3040 R310/10 1
S3044K 200 200 408 255 690 190 70 580 100 11 15.5 203 240 42 50 M36 98 23044K H3044 R340/10 1
S3048K 220 210 433 265 720 200 75 610 102 11 15.5 223 260 42 50 M36 110 23048K H3048 R360/10 1
S3052K 240 240 485 285 820 220 80 680 114 12 17.3 243 286 52 70 M45 148 23052K H3052 R400/10 1
S3056K 260 250 505 295 860 230 80 720 116 12 17.3 263 306 52 70 M45 165 23056K H3056 R420/10 1
