China Ningbo SUP bearing Co.,Ltd. established and developed on the basis of the Dalian SUPbearing factory from 2000. The company is specialized in designing and manufacturing various kinds of large-size bearings, roller derby track, roller derby tracks, slewing rings, ceramic bearings, automotive bearings, low noise deep groove ball bearing and non-standard bearing for motors, oil drillings, automobiles, water pump, power tools, large-size agricultural machines and mining machines etc. SUPbearing strictly implements the management of ISO9002 quality control system. We can take you higher quality products, roller derby track, roller derby tracks, competitive price and good service up to date.
roller derby track
roller derby tracks

Bearings NO.  d  D  B  Cr  Cor  Limiting speed  weight
mm  mm  mm  kN  kN  rpm  kg
SL183004  20 42 16 27.5 26.5 9000 0.11
SL182204  20 47 18 41 37.5 7000 0.16
SL183005  25 47 16 31.5 32.5 7500 0.12
SL182205  25 52 18 46 45 6000 0.18
SL192305  25 62 24 63 57 4500 0.37
SL183006  30 55 19 40.5 43 6500 0.2
SL182206  30 62 20 61 63 5000 0.3
SL192306  30 72 27 87 85 3800 0.56
SL183007  35 62 20 49.5 55 5500 0.26
SL182207  35 72 23 76 77 4300 0.44
SL192307  35 80 31 113 112 3400 0.74
SL183008  40 68 21 59 68 5000 0.31
SL182208  40 80 23 84 89 3800 0.55
SL192308  40 90 33 152 155 3000 1.01
SL183009  45 75 23 63 76 4600 0.4
SL182209  45 85 23 88 96 3600 0.59
SL192309  45 100 36 162 165 2700 1.37
SL183010  50 80 23 77 92 4300 0.43
SL182210  50 90 23 95 109 3300 0.64
SL192310  50 110 40 205 215 2500 1.81
SL183011  55 90 26 105 134 3700 0.64
SL182211  55 100 25 122 145 3000 0.87
SL192311  55 120 43 242 255 2300 2.28
SL182912  60 85 16 54 74 3800 0.29
SL183012  60 95 26 108 141 3500 0.69
SL182212  60 110 28 152 179 2700 1.18
SL192312  60 130 46 260 280 2100 2.88
SL182913  65 90 16 57 81 3500 0.31
SL183013  65 100 26 113 154 3200 0.73
SL182213  65 120 31 177 213 2500 1.57
SL192313  65 140 48 315 355 1900 3.52
SL182914  70 100 19 76 108 3200 0.49
SL183014  70 110 30 134 171 3100 1.02
SL182214  70 125 31 183 226 2400 1.66
SL192314  70 150 51 345 390 1800 4.33
SL182915  75 105 19 78 116 3000 0.52
SL183015  75 115 30 141 188 2800 1.06
SL182215  75 130 31 190 239 2300 1.75
SL192315  75 160 55 410 475 1700 5.3
SL182916  80 110 19 81 123 2900 0.55
SL183016  80 125 34 173 224 2600 1.43
SL182216  80 140 33 223 280 2100 2.15
SL192316  80 170 58 480 560 1600 6.32
SL182917  85 120 22 102 155 2700 0.81
SL183017  85 130 34 178 235 2500 1.51
SL182217  85 150 36 255 320 2000 2.74
SL192317  85 180 60 510 620 1500 7.34
SL182918  90 125 22 106 165 2500 0.84
SL183018  90 140 37 207 280 2300 1.97
SL182218  90 160 40 285 365 1900 3.48
SL192318  90 190 64 560 660 1400 8.83
SL182919  95 130 22 114 172 2400 0.86
SL182219  95 170 43 335 430 1700 4.17
SL192319  95 200 67 580 720 1350 10.2
SL182920  100 140 24 132 199 2300 1.14
SL183020  100 150 37 218 305 2200 2.15
SL182220  100 180 46 390 520 1600 5.13
SL192320  100 215 73 710 860 1300 13
SL182922  110 150 24 137 213 2100 1.23
SL183022  110 170 45 285 395 2000 3.5
SL182222  110 200 53 455 590 1500 7.24
SL192322  110 240 80 840 970 1150 17
SL182924  120 165 27 176 285 1900 1.73
SL183024  120 180 46 300 435 1800 3.8
SL182224  120 215 58 530 730 1400 9.08
SL192324  120 260 86 990 1220 1050 22.3
SL182926  130 180 30 210 350 1800 2.33
SL183026  130 200 52 430 610 1700 5.65
SL182226  130 230 64 630 860 1300 11.25
SL182928  140 190 30 228 375 1600 2.42
SL183028  140 210 53 455 670 1500 6.04
SL182228  140 250 68 720 1020 1200 14.17
SL182930  150 210 36 455 670 1500 3.77
SL183030  150 225 56 475 700 1500 7.33
SL182230  150 270 73 830 1180 1100 18.43
SL182932  160 220 36 320 520 1400 4
SL183032  160 240 60 540 810 1400 8.8
SL182232  160 290 80 1020 1460 1000 23
SL182934  170 230 36 330 560 1300 4.3
SL183034  170 260 67 710 1070 1300 12.2
SL182234  170 310 86 1140 1660 950 28.65
SL182936  180 250 42 410 690 1300 6.2
SL183036  180 280 74 820 1260 1200 16.1
SL182236  180 320 86 1180 1760 900 29.8
SL182938  190 260 42 455 790 1200 6.5
SL183038  190 290 75 840 1320 1100 17
SL182238  190 340 92 1300 1900 850 35.65
SL181840  200 250 24 178 320 1200 2.57
SL182940  200 280 48 550 940 1100 9.1
SL183040  200 310 82 960 1530 1100 21.8
SL182240  200 360 98 1420 2040 850 43.12
SL181844  220 270 24 187 350 1100 2.8
SL182944  220 300 48 570 1040 1000 9.9
SL183044  220 340 90 1150 1810 1000 28.4
SL181848  240 300 28 212 405 1000 4.4
SL182948  240 320 48 600 1130 950 10.6
SL183048  240 360 92 1210 1990 900 30.9
SL181852  260 320 28 222 440 950 4.71
SL182952  260 360 60 790 1460 900 18.5
SL183052  260 400 104 1620 2550 800 44.5
SL181856  280 350 33 305 600 850 7
SL182956  280 380 60 920 1740 800 19.7
SL183056  280 420 106 1660 2700 800 48
SL181860  300 380 38 375 730 800 10
SL182960  300 420 72 1180 2230 750 31.2
SL183060  300 460 118 2040 3350 700 66.6
SL181864  320 400 38 385 780 750 10.6
SL182964  320 440 72 1220 2360 700 32.9
SL183064  320 480 121 2090 3500 650 71.7
SL181868  340 420 38 395 820 700 11.2
SL182968  340 460 72 1260 2500 700 34.7
SL183068  340 520 133 2490 4150 600 95.8
SL181872  360 440 38 410 870 650 11.7
SL182972  360 480 723 290 2650 650 36.4
SL183072  360 540 134 2550 4350 550 101
SL181876  380 480 46 570 1150 600 19.2
SL182976  380 520 82 1670 3300 600 52.1
SL183076  380 560 135 2650 4550 550 106
SL181880  400 500 46 590 1220 600 20
SL182980  400 540 82 1720 3500 550 54.3
SL183080  400 600 148 3100 5500 500 140
SL181884  420 520 46 600 1260 550 20.9
SL182984  420 560 82 1750 3600 550 56.9
SL181888  440 540 46 610 1320 550 21.8
SL182988  440 600 95 2130 4200 500 78.1
SL181892  460 580 56 790 1660 500 33.9
SL182992  460 620 95 2160 4350 500 81.1
SL181896  480 600 56 800 1720 500 35.2
SL182996  480 650 100 2430 4900 480 94.7
SL1818/500  500 620 56 820 1810 480 36.5
SL1829/500  500 670 100 2460 5100 460 98.3
