Sealed Drawn Cup Needle Roller Bearings
 OD

Bearing Designation and Approx Mass Boundary Dimensions (mm

Nut Tighte- ning Torque
MA

Basic Load Rating    Limi-
ting Speed
without Eccentric Collar Mass with Eccentric Collar Mass D d C B B1 B2 G G1 M M1 C1 d2 Ecce-
ntric Cover
d1 h9
B3 e Cr Dynamic  Cor Static As Stud
Type
Limiting Radial Load Grease
Cw Cow Fr perm  For perm
mm g g mm Nm N N N rpm
16 KR 16 18 KRE 16 20 16 6 11 28 16   M6 8 4 5)   0.6 12 9 7 0.5 2.5 3650 3540 3020 3100     18000
KR 16 PP 18 KRE 16 PP 20 16 6 11 28 16   M6 8 4 5)   0.6 12 9 7 0.5 2.5 3650 3540 3020 3100     12000
KRV 16 20 KRVE 16 22 16 6 11 28 16   M6 8 4 5)   0.6 12 9 7 0.5 2.5 6000 8000 4610 6000     7200
KRV 16 PP 20 KRVE 16 PP 22 16 6 11 28 16   M6 8 4 5)   0.6 12 9 7 0.5 2.5 6000 8000 4610 6000     7200
19 KR 19  28 KRE 19  31.2 19 8 11 32 20   M8 10 4 5)   0.6 14 11 9 0.5 6.8 3820 4160 3220 3100     16000
KR 19 PP 28 KRE 19 PP 31.2 19 8 11 32 20   M8 10 4 5)   0.6 14 11 9 0.5 6.8 3820 4160 3220 3100     11300
KRV 19 32 KRVE 19 35.2 19 8 11 32 20   M8 10 4 5)   0.6 14 11 9 0.5 6.8 6300 9800 5000 6900     6000
KRV 19 PP 32 KRVE 19 PP 35.2 19 8 11 32 20   M8 10 4 5)   0.6 14 11 9 0.5 6.8 6300 9800 5000 6900     6000
22 KR 22 44 KRE 22 48.3 22 10 12 36 23   M
10X1
12 4   0.6 17 13 10 0.5 12.5 4770 5010 3450 4020     10000
KR 22 PP 44 KRE 22 PP 18.3 22 10 12 36 23   M
10X1
12 4   0.6 17 13 10 0.5 12.5 4770 5010 3450 4020     9000
KRV 22 45 KRVE 22 19.3 22 10 12 36 23   M
10X1
12 4   0.6 17 13 10 0.5 12.5 6200 9900 5300 7100     4500
KRV 22 PP 45 KRVE 22 PP 19.3 22 10 12 36 23   M
10X1
12 4   0.6 17 13 10 0.5 12.5 6200 9900 5300 7100     4500
26 KR 26 58 KRE 26 62.3 26 10 12 36 23   M 10
X1
12 4   0.6 17 13 10 0.5 12.5 4100 5500 4100 5200     10000
KR 26 PP 58 KRE 26 PP 62.3 26 10 12 36 23   M 10
X1
12 4   0.6 17 13 10 0.5 12.5 4100 5500 4100 5200     9100
KRV26 61 KRVE 26 65.3 26 10 12 36 23   M 10
X1
12 4   0.6 17 13 10 0.5 12.5 6600 9900 5320 8900     4300
KRV 26 PP 61 KRVE 26 PP 65.3 26 10 12 36 23   M 10
X1
12 4   0.6 17 13 10 0.5 12.5 6600 9900 5320 8900     4300
30 KR 30  87 KRE 30  92.5 30 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 6140 7700 5820 6400     9000
KR 30 PP 87 KRE 30 PP 92.5 30 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 6140 7700 5820 6400     6300
KRV 30 89 KRVE 30 94.5 30 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 9200 10100 7500 10600     3200
KRV 30 PP 89 KRVE 30 PP 94.5 30 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 9200 10100 7500 10600     3200
32 KR 32 98 KRE 32 103.5 32 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 6100 8700 5100 7001     9000
KR 32 PP 98 KRE 32 PP 103.5 32 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 6100 8700 5100 7001     6300
KRV 32 100 KRVE 32 105.5 32 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 8220 12600 8000 11800     3220
KRV 32 PP 100 KRVE 32 PP 105.5 32 12 14 40 25 6 M12
X1.5
13 6 3 0.6 23 15 11 0.5 18.2 8220 12600 8000 11800     3220
35 KR 35 169 KRE 35 181.5 35 16 18 52 32.5 8 M16
X1.5
17 6 3 0.8 27 20 14 1 45.8 9900 15000 7900 10100     5800
KR 35PP 169 KRE 35PP 181.5 35 16 18 52 32.5 8 M16
X1.5
17 6 3 0.8 27 20 14 1 45.8 9900 15000 7900 10100     5800
KRV 35 171 KRVE 35 183.5 35 16 18 52 32.5 8 M16
X1.5
17 6 3 0.8 27 20 14 1 45.8 10300 24000 9800 16000     2800
KRV 35 PP 171 KRVE 35 PP 183.5 35 16 18 52 32.5 8 M16
X1.5
17 6 3 0.8 27 20 14 1 45.8 10300 24000 9800 16000     2800
NUKR 35 164 NUKRE 35 176.5 35 16 18 52 32.54 8 M16
X1.5
17 6 3 0.8)4) 21 4) 20 14 1 45.8 15100 19980 10120 16300 8300 16400 4320
40 KR 40 247 KRE 40 262.8 40 18 20 58 36.5 8 M18
X1.5
19 6 3 0.8 32 22 16 1 68.7 9290 11400 8100 11500     4200
KR 40 PP 247 KRE 40 PP 262.8 40 18 20 58 36.5 8 M18
X1.5
19 6 3 0.8 32 22 16 1 68.7 9290 11400 8100 11500     4200
KRV 40 249 KRVE 40 264.8 40 18 20 58 36.5 8 M18
X1.5
19 6 3 0.8 32 22 16 1 68.7 11200 23500 10800 18500     2100
KRV 40 PP 249 KRVE 40 PP 264.8 40 18 20 58 36.5 8 M18
X1.5
19 6 3 0.8 32 22 16 1 68.7 11200 23500 10800 18500     2100
NUKR 40 242 NUKRE 40 257.8 40 18 20 58 36.5 8 M18
X1.5
19 6 3 0.8 23 22 16 1 68.7 13800 18000 12500 18800 13200 22800 4210
47 KR 47 386 KRE 47 405.5 47 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 12500 22000 10500 20500     3900
KR 47 PP 386 KRE 47 PP 405.5 47 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 12500 22000 10500 20500     3900
KRV 47 390 KRVE 47 409.5 47 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 16000 41000 16600 32000     1800
KRV 47 PP 390 KRVE 47 PP 409.5 47 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 16000 41000 16600 32000     1800
NUKR 47 380 NUKRE 47 399.5 47 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 27 24 18 1 101 30200 40000 18900 28500 10500 30000 3200
52 KR 52 461 KRE 52 480.5 52 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 10500 21000 10800 22500     3990
KR 52 PP 461 KRE 52 PP 480.5 52 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 10500 21000 10800 22500     3990
KRV 52 465 KRVE 52 484.5 52 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 22000 39000 10500 38100     1800
KRV 52 PP 465 KRVE 52 PP 484.5 52 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 37 24 18 1 101 22000 39000 10500 38100     1800
NUKR 52 450 NUKRE 52 469.5 52 20 24 66 40.5 9 M20
X1.5
21 8 4 0.8 31 24 18 1 101 37500 49300 15001 22503 10400 30500 1990
62 KR 62 790 KRE 62 818.2 62 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 20500 33000 16500 31500     2100
KR 62 PP 790 KRE 62 PP 818.2 62 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 20500 33000 16500 31500     2100
KRV 62 802 KRVE 62 830.2 62 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 31700 61000 29600 56000     1300
KRV 62 PP 802 KRVE 62 PP 830.2 62 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 31700 61000 19600 56000     1300
NUKR 62 795 NUKRE 62 823.5 62 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 38 28 22 1 205 41000 59300 40500 51000 18800 39500 1300
72 KR 72 1040 KRE 72 1068.2 72 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 41500 50300 25000 50890     2800
KR 72 PP 1040 KRE 72 PP 1068.2 72 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 20500 50000 25000 50890     2800
KRV 72 1045 KRVE 72 1073.2 72 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 31500 71000 27000 75000     1200
KRV 72 PP 1045 KRVE 72 PP 1073.2 72 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 31500 71000 27000 75000     1200
NUKR 72 1200 NUKRE 72 1038.2 72 24 29 80 49.5 11 M24
X1.5
25 8 4 0.8 44 28 22 1 205 45000 63000 35000 41000 23500 51000 1020
80 KR 80 1550 KRE 80 1610 80 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 40800 75300 24500 57000     2030
KR 80 PP 1550 KRE 80 PP 1610 80 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 40800 75300 24500 57000     2030
KRV 80 1561 KRVE 80 1621 80 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 46000 102000 39900 100600     1000
KRV 80 PP 1561 KRVE 80 PP 1621 80 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 46000 102000 39900 100600     1000
NUKR 80 1800 NUKRE 80 1600 80 30 35 100 63 15 M30
X1.5
32 8 4 1 47 35 29 1.5 351 75000 103600 50200 71000 34900 72000 1200
85 KR 85 1740 KRE 85 1800 85 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 38700 64300 29900 69000     1840
KR 85 PP 1740 KRE 85 PP 1800 85 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 38700 64300 29900 69000     1840
90 KR 90 1950 KRE 90 2010 90 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 38700 64300 29900 69000     1840
KR 90 PP 1950 KRE 90 PP 2010 90 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 38700 64300 29900 69000     1840
KRV 90 1970 KRVE 90 2030 90 30 35 100 63 15 M30
X1.5
32 8 4 1 53 35 29 1.5 351 48970 102300 38800 100000     1600
KRV 90 PP 1970 KRVE 90 PP 2030 90 30 35 100 63 15

M30
X1.5

32 8 4 1 53 35 29 1.5 351 48970 102300 38800 100000     1600
NUKR 90 2300 NUKRE 90 2020 90 30 35 100 63 15 M30
X1.5
32 8 4 1 47 35 29 1.5 351 7500 103300 51400 93000 58000 97000 1500
